RDC3072T0515
DIN Rail DC/DC Coverter, Triple OutputManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$143.00
5
$138.71
10
$134.42
25
$128.70
100
$120.12
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
36~140Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
4 Amps
Output Voltage #2:
15Vdc
Output #2 Max Current:
0.33 Amps
Output Voltage #3:
-15Vdc
Output #3 Max Current:
-0.33 Amps
Max Power:
30 Watts
