Power Worth Searching For
JTH1548S3V3
3.3Vdc 3A, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$44.00
5
$42.68
10
$41.36
25
$39.60
100
$36.96
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~72Vdc
Output Voltage:
3.3Vdc
Output Max Current:
3 Amps
Max Power:
15 Watts
Features
XP Power JTH1548S3V3 2x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+100°C
Industrial safety certification: UL 60950-1, UL 62368-1
I/O isolation: 1500Vdc
No minimum load required
Remote On/Off (-R models only)
Fully regulated output
Protections: short circuit / overcurrent / overvoltage / undervoltage-lockout
XP Power 3 year warranty
JTH1548S3V3
3.3Vdc 3A, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
18~72Vdc
Output Voltage:
3.3Vdc
Output Max Current:
3 Amps
Max Power:
15 Watts
Features
XP Power JTH1548S3V3 2x1 inches DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+100°C
Industrial safety certification: UL 60950-1, UL 62368-1
I/O isolation: 1500Vdc
No minimum load required
Remote On/Off (-R models only)
Fully regulated output
Protections: short circuit / overcurrent / overvoltage / undervoltage-lockout
XP Power 3 year warranty
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$44.00
5
$42.68
10
$41.36
25
$39.60
100
$36.96
REQUEST a QUOTE for higher qty discounts
