ITP0324D05
Dual O/P, DC/DC Converter, SIP-6, Plastic Package, 4:1 InputManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$18.67
5
$18.11
10
$17.56
25
$16.80
100
$15.68
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.3 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-0.3 Amps
Max Power:
3 Watts
Known Country of Origin:
Taiwan
Features
XP Power ITP0324D05 SIP package DC/DC converter
Ultra-wide 4:1 input range
Operating temperature range: -40~+75°C
I/O isolation: 1600Vdc
Remote On/Off (single output only)
Fully regulated output
Protections: short circuit / overcurrent
XP Power 3 year warranty
