FIHMA10C2F
10 Amp 250Vac, EMI Filter, Medical, Dual StageManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$26.22
5
$25.44
10
$24.64
25
$23.60
100
$22.02
REQUEST a QUOTE for higher qty discounts
Specifications
Filter Type:
Single Phase
# of Stages:
Dual Stage
Leakage Current:
2µA / 5µA max
Rated Current & Voltage:
10 Amps & 250 Volts
AC Connection Type:
Faston Terminals
Features
XP Power FIHMA10C2F dual stage chassis mount medical EMI noise filter
AC input max: 250Vac
Operating temperature range : -40~+110°C
Safety certification: EN 60939-2, ANSI/UL 1283
Class I
Single phase up to 264Vac
Low earth leakage current ≤5µA @ 264Vac
XP Power 3 year warranty
FIHMA10C2F
10 Amp 250Vac, EMI Filter, Medical, Dual StageManufacturer: XP Power
View Data Sheet
Specifications
Filter Type:
Single Phase
# of Stages:
Dual Stage
Leakage Current:
2µA / 5µA max
Rated Current & Voltage:
10 Amps & 250 Volts
AC Connection Type:
Faston Terminals
Features
XP Power FIHMA10C2F dual stage chassis mount medical EMI noise filter
AC input max: 250Vac
Operating temperature range : -40~+110°C
Safety certification: EN 60939-2, ANSI/UL 1283
Class I
Single phase up to 264Vac
Low earth leakage current ≤5µA @ 264Vac
XP Power 3 year warranty
