EML30US03-S

3.3 Volt DC Power Supply, Screw Terminal I/O, Class II, 3.3 Volts 6 Amps

Manufacturer: XP Power

View Data Sheet

Availability: Contact Us

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

*Import tariff may apply to this product

Quantity
Unit Price
1
$61.59
5
$57.89
10
$57.89

Specifications

Input Voltage:

85~264Vac

Output Voltage:

3.3Vdc

Output Max Current:

6 Amps

Output Peak Current:

7.8 Amps

Max Power:

20 Watts

Features

XP Power EML30US03-S chassis mount screw terminal medical power supply

AC input range: 85~264Vac

Operating temperature range: -20~+70°C

Medical safety certification: IEC/EN 60601-1, ANSI/AAMI ES 60601-1

2xMOPP

Protection Class II

Peak power

Reinforced I/O isolation 4000Vac

No load power consumption ≤0.3 watts

Protections: overvoltage / overload / short circuit

XP Power 3 year warranty

EML30US03-S

3.3 Volt DC Power Supply, Screw Terminal I/O, Class II, 3.3 Volts 6 Amps

Manufacturer: XP Power

View Data Sheet

Specifications

Input Voltage:

85~264Vac

Output Voltage:

3.3Vdc

Output Max Current:

6 Amps

Output Peak Current:

7.8 Amps

Max Power:

20 Watts

Features

XP Power EML30US03-S chassis mount screw terminal medical power supply

AC input range: 85~264Vac

Operating temperature range: -20~+70°C

Medical safety certification: IEC/EN 60601-1, ANSI/AAMI ES 60601-1

2xMOPP

Protection Class II

Peak power

Reinforced I/O isolation 4000Vac

No load power consumption ≤0.3 watts

Protections: overvoltage / overload / short circuit

XP Power 3 year warranty
