TRN 1-0512SM
12Vdc 0.09A, DC/DC Converter Wide 2:1 Input Voltage Range SMD PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
4.5~13.2Vdc
Output Voltage:
12Vdc
Output Max Current:
0.09 Amps
Max Power:
1 Watts
Features
TRACO Power TRN 1-0512SM compact SMD package DC/DC converter
SMD package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+90°C
Safety approvals: UL 60950-1 & IEC/EN 60950-1
I/O isolation 1,600Vdc
Fully regulated outputs
Protection: short circuit
TRACO Power 3 year warranty
TRN 1-0512SM
12Vdc 0.09A, DC/DC Converter Wide 2:1 Input Voltage Range SMD PackageManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
4.5~13.2Vdc
Output Voltage:
12Vdc
Output Max Current:
0.09 Amps
Max Power:
1 Watts
Features
TRACO Power TRN 1-0512SM compact SMD package DC/DC converter
SMD package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+90°C
Safety approvals: UL 60950-1 & IEC/EN 60950-1
I/O isolation 1,600Vdc
Fully regulated outputs
Protection: short circuit
TRACO Power 3 year warranty
