TRI 20-4815
24Vdc 0.84A, 20 Watt DC/DC Converter High Isolation, Regulated Compact 2"x1" PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
24Vdc
Output Max Current:
0.84 Amps
Max Power:
20 Watts
Features
TRACO Power TRI 20-4815 20W Compact 2x1 inches package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+76°C
Industrial safety approval: UL/EN/IEC 62368-1
Reinforced I/O isolation up to 5940Vdc (8000Vdc peak for 1 sec)
Low no-load power consumption 240-480mW
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
TRI 20-4815
24Vdc 0.84A, 20 Watt DC/DC Converter High Isolation, Regulated Compact 2"x1" PackageManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
24Vdc
Output Max Current:
0.84 Amps
Max Power:
20 Watts
Features
TRACO Power TRI 20-4815 20W Compact 2x1 inches package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+76°C
Industrial safety approval: UL/EN/IEC 62368-1
Reinforced I/O isolation up to 5940Vdc (8000Vdc peak for 1 sec)
Low no-load power consumption 240-480mW
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
