TPP 450-128-M
28Vdc Medical Power Supply 2xMOPP, BF Rated Enclosed with Fan
Manufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
9.4 Amps
Max Power:
450 Watts
Features
TRACO Power TPP 450-148-M high power density enclosed medical & industrial power supply with fan
AC input range: 85~264Vac
Operating temperature range: -40~+80°C (with derating)
Medical safety approvals: ANSI/AAMI ES 60601-1 & IEC/EN/ES 60601-1 3rd edition
Industrial safety approval: UL 62368-1
2xMOPP
Suitable for BF applications
EMC emission to IEC/EN 60601-1-2 4th Edition
Low leakage current <100µA
Integrated variable fan speed control
5V standby
Remote On/Off, Power Good signal
Adjustable output voltage
Built-in PFC
High efficiency
Operation up to 5000m altitude
Protections: short circuit / over load / over voltage
TRACO Power 5 year warranty
TPP 450-128-M
28Vdc Medical Power Supply 2xMOPP, BF Rated Enclosed with Fan
Manufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
9.4 Amps
Max Power:
450 Watts
Features
TRACO Power TPP 450-148-M high power density enclosed medical & industrial power supply with fan
AC input range: 85~264Vac
Operating temperature range: -40~+80°C (with derating)
Medical safety approvals: ANSI/AAMI ES 60601-1 & IEC/EN/ES 60601-1 3rd edition
Industrial safety approval: UL 62368-1
2xMOPP
Suitable for BF applications
EMC emission to IEC/EN 60601-1-2 4th Edition
Low leakage current <100µA
Integrated variable fan speed control
5V standby
Remote On/Off, Power Good signal
Adjustable output voltage
Built-in PFC
High efficiency
Operation up to 5000m altitude
Protections: short circuit / over load / over voltage
TRACO Power 5 year warranty
