Power Worth Searching For
TMR 3-1222WIE
Dual O/P, DC-DC Converter SIP-8 Package Wide 4:1 Input Voltage RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$17.50
10
$15.32
25
$14.73
100
$12.68
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
4.5~18Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.125 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.125 Amps
Max Power:
3 Watts
Features
TRACO Power TMR 3-1222WIE compact SIP-8 package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+85°C
I/O isolation 1500Vdc
Remote On/Off control
Short circuit protection
TRACO Power 3 year warranty
TMR 3-1222WIE
Dual O/P, DC-DC Converter SIP-8 Package Wide 4:1 Input Voltage RangeManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
4.5~18Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.125 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.125 Amps
Max Power:
3 Watts
Features
TRACO Power TMR 3-1222WIE compact SIP-8 package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+85°C
I/O isolation 1500Vdc
Remote On/Off control
Short circuit protection
TRACO Power 3 year warranty
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$17.50
10
$15.32
25
$14.73
100
$12.68
REQUEST a QUOTE for higher qty discounts
