THN 10-2421WIR

Dual O/P, 1x1 DC/DC Railway Converter Metal Package 4:1 Input Range

Manufacturer: TRACO Power

View Data Sheet

Availability: Contact Us

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

Quantity
Unit Price
1
$39.96
10
$35.11
25
$34.19
50
$30.06

Specifications

Input Voltage:

9~36Vdc

Output Voltage #1:

5Vdc

Output #1 Max Current:

1 Amps

Output Voltage #2:

-5Vdc

Output #2 Max Current:

1 Amps

Max Power:

10 Watts

Features

TRACO Power THN 10-2421WIR compact 1x1 metal package DC/DC converter

Ultra wide 4:1 input voltage range

Operating temperature: -40~+80°C

Safety certifications: IEC/EN/UL 62368-1

EN 50155 and EN 61373 for railway applications

I/O isolation 3000Vdc

Output voltage trim function

Under-voltage lock out circuit

Remote On/Off

Protections: short circuit / over load / over voltage

TRACO Power 3 year warranty
