THM 20-4821
Dual O/P, Medical DC/DC Converter Wide 2:1 Input Voltage Range 2xMOPP, Dual OutputManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
36~75Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.5 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.5 Amps
Max Power:
15 Watts
Features
TRACO Power THM 20-4821 medical plastic 1.6 x 1 inch package DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+80°C
Medical safety approvals: ANSI/AAMI ES 60601-1 & IEC/EN 60601-1 3rd edition
2xMOPP
Risk management process according to ISO 14971 including risk management file
Acceptance criteria for electronic assemblies according to IPC-A-610 Level 3
Low leakage current <2.5µA
I/O isolation 5000 Vacrms rated for 250 Vacrms working voltage
EMC compliance to IEC 60601-1-2 4th edition and EN55032 class A
Operating up to 5000m altitude
Protections: short circuit / over voltage / over load / over temperature
TRACO Power 5 year warranty
