THI 0521
Dual O/P, DC-DC Converter DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$37.49
10
$32.46
25
$31.19
100
$25.92
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
4.5~5.5Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.08 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.08 Amps
Max Power:
2 Watts
Features
TRACO Power THI 0521 DIP-24 package DC/DC converter
Operating temperature: -40~+85°C
I/O isolation voltage 2500Vacrms
Supplementary insulation rated for working voltage up to 250Vac
Regulated output
Low coupling capacity
Short circuit protection
TRACO Power 3 year warranty
THI 0521
Dual O/P, DC-DC Converter DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
4.5~5.5Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.08 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
0.08 Amps
Max Power:
2 Watts
Features
TRACO Power THI 0521 DIP-24 package DC/DC converter
Operating temperature: -40~+85°C
I/O isolation voltage 2500Vacrms
Supplementary insulation rated for working voltage up to 250Vac
Regulated output
Low coupling capacity
Short circuit protection
TRACO Power 3 year warranty
