TEN 8-4810WI
3.3Vdc 2.4A, DC/DC Converter DIP-24, Railway Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
3.3Vdc
Output Max Current:
2.4 Amps
Max Power:
7.92 Watts
Features
TRACO Power TEN 8-4810WI DIP-24 metal package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+85°C
No minimum load required
EN 50155 approval for demanding applications such as railway and transportation
Under voltage lockout
Thermal shock and vibration resistant according EN 61373
Shielded metal case with insulated baseplate
Protections: short circuit / over load / over voltage (single output models only)
Remote On/Off
TRACO Power 3 year warranty
TEN 8-4810WI
3.3Vdc 2.4A, DC/DC Converter DIP-24, Railway Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
3.3Vdc
Output Max Current:
2.4 Amps
Max Power:
7.92 Watts
Features
TRACO Power TEN 8-4810WI DIP-24 metal package DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+85°C
No minimum load required
EN 50155 approval for demanding applications such as railway and transportation
Under voltage lockout
Thermal shock and vibration resistant according EN 61373
Shielded metal case with insulated baseplate
Protections: short circuit / over load / over voltage (single output models only)
Remote On/Off
TRACO Power 3 year warranty
