TBA 1-2422E
Dual O/P, 1 Watt DC/DC Converter SIP-7 Plastic Package UnregulatedManufacturer: TRACO Power
View Data Sheet
In Stock: 10 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$3.15
10
$3.11
25
$3.03
100
$2.93
250
$2.89
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
21.6~26.4Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.041 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.041 Amps
Max Power:
1 Watts
Features
TRACO Power TBA 1-2422E compact plastic SIP-7 package DC/DC converter
Input voltage range (±10%)
Operating temperature: -40~+95°C
I/O isolation 1500Vdc
Unregulated output
Protections: short circuit
TRACO Power 3 year warranty
