Power Worth Searching For
RSDW10H-15
10W I/P: 43-160VDC; O/P: 15V@666mA, 15Vdc DC/DC Converter Ultra Wide Input Voltage Range DIP-24, Railway, 10 WattsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$27.82
10
$27.46
25
$27.10
50
$26.75
100
$26.08
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
43~160Vdc
Output Voltage:
15Vdc
Output Max Current:
0.666 Amps
Max Power:
10 Watts
Known Country of Origin:
China
Features
Ultra wide input voltage range
Operating temperature range: -40~+85°C
Complies to EN 50155 railway standard
3000Vdc I/O isolation
Single output
No minimum load required
Remote On/Off
Protections: continuous short circuit / over load / over voltage / input under voltage
MEAN WELL 3 year warranty
