LDB-300L
I/P:9-36VDC; O/P:2-40V@300mA, Constant Current DC/DC Converter, Pin TypeManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$10.35
10
$8.87
20
$8.63
100
$8.28
200
$8.18
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Constant Current:
300 mA
Constant Current Operating Range:
2~40 Vdc
Max Power:
1 Watts
Known Country of Origin:
Taiwan
Features
DC/DC buck-boost converter
Wide input voltage: 9~36Vdc
Wide output LED string voltage: 2~40Vdc
Operating Voltage: -40~+70°C
High efficiency up to 90%
Comply with BS EN/EN55015 and FCC part 15
Built-in PWM and remote ON/OFF control
Cooling by free air convection
Fully encapsulated with IP67 level
Protections: Short circuit / Over temperature
Mean Well 3 year product warranty
