Power Worth Searching For
DPBW03F-05
I/P:9-36VDC; O/P:+/- 5V @+/-300mA; SIP DC-DC Converter SIPManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$11.24
10
$11.09
25
$10.94
50
$10.81
100
$10.54
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.3 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-0.3 Amps
Max Power:
3 Watts
Known Country of Origin:
China
Features
Ultra wide 4:1 input voltage range
Operating temperature: -40~+85°C
Comply to EN55032 radiated Class A without additional components
Dual output
High efficiency
I/O isolation 1.5K Vdc
No minimum load required
Remote On/Off
Protections: short circuit (continuous) / over load / input under voltage
MEAN WELL 3 year warranty
