DKMW06F-24

DC/DC Converter DIP Package 4:1 Input

Manufacturer: MEAN WELL

View Data Sheet

Availability: Contact Us

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

*The import tariff is included in the unit price

Quantity
Unit Price
1
$12.73
10
$12.56
25
$12.40
50
$12.24
100
$11.94

Specifications

Input Voltage:

9~36Vdc

Output Voltage #1:

24Vdc

Output #1 Max Current:

0.125 Amps

Output Voltage #2:

-24Vdc

Output #2 Max Current:

0.125 Amps

Max Power:

6 Watts

Features

Ultra-Wide 4:1 input range

Operating temperature range: -40~+85°C

Industrial safety certification: UL 60950-1

I/O isolation: 1500Vdc

Dual output

No minimum load required

Black coated copper case with non-conductive base

Protections: short circuit / overload / overvoltage / input under voltage

MEAN WELL 3 year warranty

DKMW06F-24

DC/DC Converter DIP Package 4:1 Input

Manufacturer: MEAN WELL

View Data Sheet

Specifications

Input Voltage:

9~36Vdc

Output Voltage #1:

24Vdc

Output #1 Max Current:

0.125 Amps

Output Voltage #2:

-24Vdc

Output #2 Max Current:

0.125 Amps

Max Power:

6 Watts

Features

Ultra-Wide 4:1 input range

Operating temperature range: -40~+85°C

Industrial safety certification: UL 60950-1

I/O isolation: 1500Vdc

Dual output

No minimum load required

Black coated copper case with non-conductive base

Protections: short circuit / overload / overvoltage / input under voltage

MEAN WELL 3 year warranty
