DETN01M-15

DC/DC Converter Dual Output, Unregulated SMD Type

Manufacturer: MEAN WELL

View Data Sheet

Availability: Contact Us

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

Quantity
Unit Price
1
$4.67
10
$4.61
25
$4.55
50
$4.49
100
$4.38

Specifications

Input Voltage:

10.8~13.2Vdc

Output Voltage #1:

15Vdc

Output #1 Max Current:

0.034 Amps

Output Voltage #2:

-15Vdc

Output #2 Max Current:

-0.034 Amps

Max Power:

1 Watts

Features

Operating temperature: -40~+90°C

I/O isolation: 3,000Vdc

Industry standard pinout

Complies to EN55032 radiated Class B without additional components

Protections: short circuit

MEAN WELL 3 year warranty
