Power Worth Searching For
DC4-70-1002-CH
DC/DC Converter, ChassisManufacturer: IPD
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$104.35
3
$101.24
10
$99.75
25
$94.61
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
36~72Vdc
Output Voltage:
3.3Vdc
Output Max Current:
14 Amps
Max Power:
46 Watts
Features
IPD DC4-70-1002-CH DC/DC converter with medical approvals
DC input range: 36~72Vdc (48Vdc)
Operating temperature: 0~+70°C
EN 60950-1 ITE certification and EN 60601-1 medical certification
Small compact size, chassis dimensions: 2.62x4.79x1.48
Available in open frame or optional cover
Protections: over voltage / over power
Integrated Power Designs 2 year warranty
