QHL150300S12
12Vdc 12.5A, DC/DC Converter, Quarter BrickManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$158.06
5
$153.32
10
$148.58
25
$142.25
100
$132.77
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
180~425Vdc
Output Voltage:
12Vdc
Output Max Current:
12.5 Amps
Max Power:
150 Watts
Features
XP Power QHL150300S12 industrial DC/DC converter
180~425Vdc input range
Operating temperature range: -40~+100°C
Industrial safety certification: UL 60950-1
MIL-STD-810F
Compliance to IEC 61373 for shock and vibration
I/O isolation: 3000Vac
No minimum load required
Remote On/Off
Remote sense function
Output voltage trim function
Fully regulated output
Protections: short circuit / overload / overvoltage / over temperature / undervoltage-lockout
XP Power 3 year warranty
