JHM2048S05
5Vdc 4A, Medical DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$62.92
5
$61.03
10
$59.14
25
$56.63
100
$52.85
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
5Vdc
Output Max Current:
4 Amps
Max Power:
20 Watts
Features
XP Power JHM2048S05 2x1 inches medical DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+80°C
Medical safety certification: ANSI/AAMI ES/IEC/EN 60601-1
2xMOPP
2.5µA patient leakage current
I/O isolation: 4000Vac
Output voltage trim function
No minimum load required
Fully regulated output
Protections: short circuit / overload / overvoltage / undervoltage lockout
XP Power 3 year warranty
