JHM1012D15
Dual O/P, Medical DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$56.60
5
$54.90
10
$53.20
25
$50.94
100
$47.54
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.333 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
-0.333 Amps
Max Power:
10 Watts
Features
XP Power JHM1012D15 medical DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+80°C
Medical safety certification: ANSI/AAMI ES/IEC/EN 60601-1
2xMOPP
2µA patient leakage current
Input filter meets EN 55032 class A
I/O isolation: 4000Vac
Output voltage trim function
No minimum load required
Fully regulated output
Protections: short circuit / overload / overvoltage
XP Power 3 year warranty
