JCM1548S05
5Vdc 3A, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$33.83
5
$32.82
10
$31.80
25
$30.45
100
$28.42
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
5Vdc
Output Max Current:
3 Amps
Max Power:
15 Watts
Features
XP Power JCM1548S05 1x1 inches DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+105°C
Industrial safety certification: UL 60950-1, UL 62368-1
Input filter meets EN 55022 class A
I/O isolation: 1600Vac
No minimum load required
Output voltage trim function (single ouput)
Remote On/Off
Fully regulated output
Protections: short circuit / overload / overvoltage
XP Power 3 year warranty
JCM1548S05
5Vdc 3A, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
36~75Vdc
Output Voltage:
5Vdc
Output Max Current:
3 Amps
Max Power:
15 Watts
Features
XP Power JCM1548S05 1x1 inches DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+105°C
Industrial safety certification: UL 60950-1, UL 62368-1
Input filter meets EN 55022 class A
I/O isolation: 1600Vac
No minimum load required
Output voltage trim function (single ouput)
Remote On/Off
Fully regulated output
Protections: short circuit / overload / overvoltage
XP Power 3 year warranty
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$33.83
5
$32.82
10
$31.80
25
$30.45
100
$28.42
REQUEST a QUOTE for higher qty discounts
