JCG1212D12
Dual O/P, DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$33.55
5
$32.54
10
$31.54
25
$30.20
100
$28.18
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.5 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.5 Amps
Max Power:
15 Watts
Features
XP Power JCG1212D12 DIP package DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+100°C
Input filter meets EN 55022 class A
I/O isolation: 1600Vdc
Remote On/Off
No minimum load required
Fully regulated output
Protections: short circuit / overload / overvoltage
XP Power 3 year warranty
