JCE0312D24
DC/DC ConverterManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$15.95
5
$15.47
10
$14.99
25
$14.36
100
$13.40
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
24Vdc
Output #1 Max Current:
0.063 Amps
Output Voltage #2:
-24Vdc
Output #2 Max Current:
-0.063 Amps
Max Power:
3 Watts
Features
XP Power JCE0312D24 DIP package DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+100°C
Input filter meets EN 55022 class A
I/O isolation: 1500Vdc
No minimum load required
Fully regulated output
Protections: short circuit
XP Power 3 year warranty
JCE0312D24
DC/DC ConverterManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
24Vdc
Output #1 Max Current:
0.063 Amps
Output Voltage #2:
-24Vdc
Output #2 Max Current:
-0.063 Amps
Max Power:
3 Watts
Features
XP Power JCE0312D24 DIP package DC/DC converter
Wide 2:1 input range
Operating temperature range: -40~+100°C
Input filter meets EN 55022 class A
I/O isolation: 1500Vdc
No minimum load required
Fully regulated output
Protections: short circuit
XP Power 3 year warranty
