IML0215D03
Dual O/P, Medical DC/DC Converter, SIP-7, Plastic Package, Dual OutputManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$8.35
5
$8.10
10
$7.85
25
$7.52
100
$7.01
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
13.5~16.5Vdc
Output Voltage #1:
3.3Vdc
Output #1 Max Current:
0.303 Amps
Output Voltage #2:
-3.3Vdc
Output #2 Max Current:
-0.303 Amps
Max Power:
2 Watts
Features
XP Power IML0215D03 SIP-7 package medical DC/DC converter
Operating temperature range: -40~+85°C
Medical safety certification: ANSI/AAMI ES/IEC/EN 60601-1
Patient leakage current 2µA
I/O isolation: 4000Vac
Fully regulated output
Operation up to 5000m altitude
Protections: short circuit
XP Power 3 year warranty
