TMR 2-4812WIN
12Vdc 0.167A, DC-DC Converter SIP-8 Package Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$15.70
10
$13.78
25
$13.25
100
$11.40
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
12Vdc
Output Max Current:
0.167 Amps
Max Power:
2 Watts
Features
TRACO Power TMR 2-4812WIN compact SIP-8 DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+90°C
I/O isolation 1,500Vdc
High efficiency
Excellent load and line regulation
Remote On/Off control
Protections: short circuit / overload
TRACO Power 3 year warranty
TMR 2-4812WIN
12Vdc 0.167A, DC-DC Converter SIP-8 Package Ultra Wide 4:1 Input RangeManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
12Vdc
Output Max Current:
0.167 Amps
Max Power:
2 Watts
Features
TRACO Power TMR 2-4812WIN compact SIP-8 DC/DC converter
Ultra wide 4:1 input voltage range
Operating temperature: -40~+90°C
I/O isolation 1,500Vdc
High efficiency
Excellent load and line regulation
Remote On/Off control
Protections: short circuit / overload
TRACO Power 3 year warranty
