TEC 3-2422UI
12V -12V, 3W, 12V 0.125A, SIP-8 DC/DC Converter, 9~75 Volt Ultra-wide Input Range, Dual OutputManufacturer: TRACO Power
View Data Sheet
In Stock: 10 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.125 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.125 Amps
Max Power:
3 Watts
Features
SIP-8, PCB mount, DC/DC converter
Ultra wide 9~75Vdc input range
Operating temperature range: -40~+90°C
Industrial safety certification: IEC/EN 62368-1
I/O isolation: 2000Vdc
MIL-STD-202
Built-in remote On/Off
Withstands 10G vibration
Operation up to 5000m altitude
Under voltage lock-out circuit
Protections: short circuit / overcurrent
TRACO Power 3 year warranty
