TEN 30-3612UIR
12Vdc 2.5A, 30 Watt, 12V, 2.5A, 9~75 Volt (12:1) Ultra-wide Input Range, 2x1 Railway DC/DC ConverterManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~75Vdc
Output Voltage:
12Vdc
Output Max Current:
2.5 Amps
Max Power:
30 Watts
Features
2x1, fully encapsulated, railway DC/DC converter
Ultra wide 12:1 input range
Operating temperature range: -40~+85°C (up to +90°C with optional heat-sink)
Industrial safety certification: IEC/EN 62368-1, UL 62368-1
Certified to EN 50155 railway standard
Certified to EN 61373 for shock & vibration
MIL-STD-810F
I/O isolation: 3000Vdc
Built-in remote On/Off
Adjustable output voltage
Operation up to 5000m altitude
Under voltage lock-out circuit
Over voltage category II
Protections: short circuit / overvoltage / over temperature
TRACO Power 3 year warranty
