TRA 1-0521
Dual O/P, DC-DC Converter SIP-6 Package Semi-RegulatedManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
4.5~5.5Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.1 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
0.1 Amps
Max Power:
1 Watts
Features
TRACO Power TRA 1-0521 SIP-6 package semi-regulated DC/DC converter
Operating temperature: -40~+85°C
I/O isolation 1,000Vdc
High efficiency
Industry standard pinout
Reliable up to 5,000m altitude
Short circuit protection
TRACO Power 3 year warranty
