THI 3-2411
5Vdc 0.6A, Medical DC-DC Converter DIP-24 Package 2XMOOPManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$30.35
10
$26.26
25
$25.23
100
$20.97
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
21.6~26.4Vdc
Output Voltage:
5Vdc
Output Max Current:
0.6 Amps
Max Power:
3 Watts
Features
TRACO Power THI 3-2411 high isolation DIP-24 medical DC/DC converter
Operating temperature: -40~+75°C
Medical safety approvals: AAMI/ANSI ES 60601-1:2005(R) & IEC/EN 60601-1 3rd edition
Industrial safety approvals: UL/IEC/EN 60950-1
2xMOOP
Supplementary and reinforced insulation
Fully regulated output voltage
I/O isolation 4000Vacrms rated for 300 Vrms working voltage
Input filter meets EN 55022, class A and FCC, level A
Low leakage current
Low coupling capacitance
Short circuit protection
TRACO Power 3 year warranty
