TRI 6-2411
5Vdc 1.2A, 6 Watt DC/DC Converter High Isolation, Regulated Compact DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~36Vdc
Output Voltage:
5Vdc
Output Max Current:
1.2 Amps
Max Power:
6 Watts
Features
TRACO Power TRI 6-2411 DIP-24 package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+95°C
Industrial safety approval: UL/EN/IEC 62368-1
Reinforced I/O isolation up to 7071Vdc (9000Vdc peak for 1 sec)
Low no-load power consumption 120-240mW
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
TRI 6-2411
5Vdc 1.2A, 6 Watt DC/DC Converter High Isolation, Regulated Compact DIP-24 PackageManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
18~36Vdc
Output Voltage:
5Vdc
Output Max Current:
1.2 Amps
Max Power:
6 Watts
Features
TRACO Power TRI 6-2411 DIP-24 package DC/DC converter
Wide 2:1 input voltage range
Operating temperature range: -40~+95°C
Industrial safety approval: UL/EN/IEC 62368-1
Reinforced I/O isolation up to 7071Vdc (9000Vdc peak for 1 sec)
Low no-load power consumption 120-240mW
Protections: short circuit / over load / over voltage
TRACO Power 3 year warranty
