TEN 40-1223
Dual O/P, DC-DC Converter 2x2Manufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
1.4 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
1.4 Amps
Max Power:
30 Watts
Features
TRACO Power TEN 40-1223 2x2 inch low profile DC/DC converter
Wide 2:1 input range
Operating temperature: -40~+75°C
Safety approvals: UL/IEC/EN 60950-1
Available models with single, dual and triple output
Shielded metal package with insulated baseplate
Under voltage lockout
Remote On/Off
Protections: short circuit / over load / over voltage / thermal shutdown
Optional heat sink available
TRACO Power 3 year warranty
TEN 40-1223
Dual O/P, DC-DC Converter 2x2Manufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
9~18Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
1.4 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
1.4 Amps
Max Power:
30 Watts
Features
TRACO Power TEN 40-1223 2x2 inch low profile DC/DC converter
Wide 2:1 input range
Operating temperature: -40~+75°C
Safety approvals: UL/IEC/EN 60950-1
Available models with single, dual and triple output
Shielded metal package with insulated baseplate
Under voltage lockout
Remote On/Off
Protections: short circuit / over load / over voltage / thermal shutdown
Optional heat sink available
TRACO Power 3 year warranty
