TCL 024-105 DC
5Vdc 5A, 5V DIN Rail DC/DC Converter UL 508 ListedManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
18~75Vdc
Output Voltage:
5Vdc
Output Max Current:
5 Amps
Max Power:
25 Watts
Features
TRACO Power TCL 024-105 DC DIN rail DC/DC converter
Wide DC input voltage range
Operating temperature range: -25~+70°C
UL508C listed, cUL/UL60950-1
I/O isolation: 1500Vdc
Adjustable output voltage
DC OK LED indicator
Plastic case (UL94V-0 rated)
Detachable screw terminals for easy connection
Standard Protections: reverse polarity / over voltage / short circuit
TRACO Power 3 year warranty
