Power Worth Searching For
TMR 1-0512SM
12Vdc 0.083A, DC-DC Converter SMD Package I/O Isolation 1500 VoltManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
4.5~9Vdc
Output Voltage:
12Vdc
Output Max Current:
0.083 Amps
Max Power:
1 Watts
Features
TRACO Power TMR 1-0512SM compact SMD package DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+82°C
I/O isolation 1,500Vdc
Fully regulated outputs
No minimum load required
Remote On/Off control
Protections: short circuit / over load
TRACO Power 3 year warranty
TMR 1-0512SM
12Vdc 0.083A, DC-DC Converter SMD Package I/O Isolation 1500 VoltManufacturer: TRACO Power
View Data Sheet
Specifications
Input Voltage:
4.5~9Vdc
Output Voltage:
12Vdc
Output Max Current:
0.083 Amps
Max Power:
1 Watts
Features
TRACO Power TMR 1-0512SM compact SMD package DC/DC converter
Wide 2:1 input voltage range
Operating temperature: -40~+82°C
I/O isolation 1,500Vdc
Fully regulated outputs
No minimum load required
Remote On/Off control
Protections: short circuit / over load
TRACO Power 3 year warranty
