TES 2-2423H
Dual O/P, DC-DC Converter SMD PackageManufacturer: TRACO Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
21.6~26.4Vdc
Output Voltage #1:
15Vdc
Output #1 Max Current:
0.066 Amps
Output Voltage #2:
-15Vdc
Output #2 Max Current:
0.066 Amps
Max Power:
2 Watts
Features
TRACO Power TES 2-2423H compact SMD package DC/DC converter
Operating temperature: -40~+85°C
I/O isolation 1500Vdc
High efficiency
High accuracy of pin co-planarity
Available tape and reel package
Short circuit protection
TRACO Power 3 year warranty
