MDS02M-12N

2W; I/P: 12VDC; O/P: 12VDC@167mA; SIP Medical DC/DC Converter, SIP-7, 2xMOOP

Manufacturer: MEAN WELL

View Data Sheet

Availability: Contact Us

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

Quantity
Unit Price
1
$4.67
10
$4.61
25
$4.55
50
$4.49
100
$4.38

Specifications

Input Voltage:

10.8~13.2Vdc

Output Voltage:

12Vdc

Output Max Current:

0.167 Amps

Max Power:

2 Watts

Features

Medical SIP-7 DC/DC converter

Input voltage range: 10.8~13.2Vdc

Operating temperature range: -40~+95°C

I/O isolation: 6,000Vdc

Industrial safety certification: IEC 62368-1, UL 62368-1

Medical safety certification: IEC 60601-1

2xMOOP

Low leakage current <2µA

Protections: short circuit (continuous)

MEAN WELL 3 year warranty

MEAN WELL MDS02M-12N

MDS02M-12N

2W; I/P: 12VDC; O/P: 12VDC@167mA; SIP Medical DC/DC Converter, SIP-7, 2xMOOP

Manufacturer: MEAN WELL

View Data Sheet

Specifications

Input Voltage:

10.8~13.2Vdc

Output Voltage:

12Vdc

Output Max Current:

0.167 Amps

Max Power:

2 Watts

Features

Medical SIP-7 DC/DC converter

Input voltage range: 10.8~13.2Vdc

Operating temperature range: -40~+95°C

I/O isolation: 6,000Vdc

Industrial safety certification: IEC 62368-1, UL 62368-1

Medical safety certification: IEC 60601-1

2xMOOP

Low leakage current <2µA

Protections: short circuit (continuous)

MEAN WELL 3 year warranty
