Power Worth Searching For
RDDW20UW-12
20W I/P: 8.5-160VDCO/P :+/-12V@+/-0~833mA, DC/DC Converter 2x1 18:1 Input, dual outputManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$69.55
10
$68.64
25
$67.74
50
$66.88
100
$65.20
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
8.5~160Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.833 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.833 Amps
Max Power:
20 Watts
Known Country of Origin:
China
Features
Ultra-wide 18:1 input range
Operating temperature range: -40~+95°C
Industrial safety certification: UL 62368-1
Compliance to EN 50155 railway standard
Compliance to IEC 61373 for shock & vibration
I/O isolation: 3000Vac
Dual output
No minimum load required
Fully regulated output
Remote On/Off
Operation up to 5000m altitude
Shielded metal case with isolated baseplate
Protections: short circuit / overload / overcurrent / input under voltage
MEAN WELL 3 year warranty
