RDDW20F-12
20W I/P: 9-36VDC; O/P :+/-12V@+/-0 ~835mA, Dual Output DC/DC Converter Ultra Wide 4:1 Input Range DIP, 2x1", RailwayManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$44.58
10
$43.99
25
$43.43
50
$42.87
100
$41.80
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
9~36Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.835 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.835 Amps
Max Power:
20 Watts
Known Country of Origin:
China
Features
Ultra wide 4:1 input voltage range
Operating temperature range: -40~+85°C
Complies to EN 50155 railway standard
1500Vdc I/O isolation
Dual output
No minimum load required
Remote On/Off
Fully encapsulated
Protections: continuous short circuit / over load / over voltage / input under voltage
MEAN WELL 3 year warranty
