Power Worth Searching For
RDDW08G-12
8W I/P: 18-75VDC; O/P :+/-12V@+/-0 ~333mA, Dual Output DC/DC Converter Wide Input Voltage Range DIP-24, RailwayManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$21.23
10
$20.95
25
$20.66
50
$20.41
100
$19.90
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.333 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.3 Amps
Max Power:
8 Watts
Known Country of Origin:
China
Features
Ultra wide 4:1 input voltage range
Operating temperature range: -40~+85°C
Complies to EN 50155 railway standard
1500Vdc I/O isolation
Dual output
No minimum load required
Remote On/Off
Protections: continuous short circuit / over load / over voltage / input under voltage
MEAN WELL 3 year warranty
RDDW08G-12
8W I/P: 18-75VDC; O/P :+/-12V@+/-0 ~333mA, Dual Output DC/DC Converter Wide Input Voltage Range DIP-24, RailwayManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
18~75Vdc
Output Voltage #1:
12Vdc
Output #1 Max Current:
0.333 Amps
Output Voltage #2:
-12Vdc
Output #2 Max Current:
-0.3 Amps
Max Power:
8 Watts
Known Country of Origin:
China
Features
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$21.23
10
$20.95
25
$20.66
50
$20.41
100
$19.90
REQUEST a QUOTE for higher qty discounts
