EML15US03-P
3.3Vdc 3A, Open Frame Power Supply, PCB Mount, Class II, 3.3 Volts 3 AmpsManufacturer: XP Power
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$39.28
5
$38.11
10
$36.93
25
$35.35
100
$32.99
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
85~264Vac
Output Voltage:
3.3Vdc
Output Max Current:
3 Amps
Output Peak Current:
3.9 Amps
Max Power:
10 Watts
Features
XP Power EML15US03-P PCB mount medical power supply
AC input range: 85~264Vac
Operating temperature range: -20~+70°C
Medical safety certification: IEC/EN 60601-1, ANSI/AAMI ES 60601-1
2xMOPP
Protection Class II
Adjustable output voltage
Peak power
Reinforced I/O isolation 4000Vac
High power density: 4.8W/in³
No load power consumption ≤0.3 watts
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
EML15US03-P
3.3Vdc 3A, Open Frame Power Supply, PCB Mount, Class II, 3.3 Volts 3 AmpsManufacturer: XP Power
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage:
3.3Vdc
Output Max Current:
3 Amps
Output Peak Current:
3.9 Amps
Max Power:
10 Watts
Features
XP Power EML15US03-P PCB mount medical power supply
AC input range: 85~264Vac
Operating temperature range: -20~+70°C
Medical safety certification: IEC/EN 60601-1, ANSI/AAMI ES 60601-1
2xMOPP
Protection Class II
Adjustable output voltage
Peak power
Reinforced I/O isolation 4000Vac
High power density: 4.8W/in³
No load power consumption ≤0.3 watts
Protections: overvoltage / overload / short circuit
XP Power 3 year warranty
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$39.28
5
$38.11
10
$36.93
25
$35.35
100
$32.99
REQUEST a QUOTE for higher qty discounts
