PAA30B-13
15V PCB Mount Power Supply Encapsulated 15 Volts 2 AmpsManufacturer: TT Electronics
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$43.37
10
$42.74
50
$34.57
100
$29.47
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
90~305Vac
Output Voltage:
15Vdc
Output Max Current:
2 Amps
Max Power:
30 Watts
Features
Power Partners PAA30B-13 encapsulated AC/DC power supply
AC input range: 90~305Vac
Operating temperature range: -40~+70°C
Class II isolation
Industrial safety certification: IEC/EN 60950-1, IEC/EN 62368-1, UL 62368-1
EMC compliant without external components
Class B conducted & radiated emissions
I/O isolation 4000Vac
No load power consumption <0.1 watt
Protections: overvoltage / overload / short circuit
TT Electronics 1 year warranty
