TDR-480-48
48 Volts 10A, 48Vdc DIN Rail Power Supply 3 Phase Wide Input Range 48V 10A, 480 WattsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$147.09
5
$140.07
10
$133.86
20
$130.07
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
340~550Vac Three Phase
Output Voltage:
48Vdc
Output Max Current:
10 Amps
Max Power:
480 Watts
Features
AC input range: 340~550Vac (3-phase input voltage)
Operating temperature range: -30~+70°C
Industrial safety certification: IEC 62368-1
UL508 listed (industrial control equipment)
High efficiency
Built-in constant current limiting circuit
Optional DC OK relay contact
Installs on DIN rail TS-35/7.5 or 15
Standard protections: short circuit / over load / over voltage / over temperature
MEAN WELL 3 year warranty
