SDR-480P-48
48Vdc 10A, 48Vdc DIN Rail Power Supply Current Sharing (7+1) 48V 10A, 480 WattsManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$151.10
5
$143.90
10
$137.50
20
$133.60
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
88~264Vac
Output Voltage:
48Vdc
Output Max Current:
10 Amps
Output Peak Current:
15 Amps
Max Power:
480 Watts
Features
Complies with GL Marine and SEMI F47
Installs on DIN rail TS35 / 7.5 or 15
Operating temperature range: -25~+70°C
Current sharing capability up to 3840W (7+1)
High efficiency power supply
Built-in DC OK relay contact
Built-in active PFC function
Peak load capability - 720 Watts for 3 seconds
Standard Protections: short circuit / overload / over voltage / over temperature
Mean Well 3 years warranty
