SDR-240-24
24Vdc 10A, 24Vdc DIN Rail Power Supply PFC, Peak Current 24V 10A, 240 WattsManufacturer: MEAN WELL
View Data Sheet
In Stock: 905 can ship immediately
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
88~264Vac
Output Voltage:
24Vdc
Output Max Current:
10 Amps
Output Peak Current:
15 Amps
Max Power:
240 Watts
Features
AC input range: 88~264Vac
Operating temperature range: -25~+70°C
Complies with GL Marine and SEMI F47
Installs on DIN rail TS35 / 7.5 or 15
High efficiency
Built-in DC OK relay contact
Built-in active PFC function
Peak load capability
Standard protections: short circuit / overload / over voltage / over temperature
MEAN WELL 3 year warranty
