LRS-150-24

24Vdc 6.5A, Power Supply, 24 Volts, 150 Watts

Manufacturer: MEAN WELL

View Data Sheet

In Stock: 218 can ship immediately

i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.

Lead time for quantities greater than shown, contact us

*The import tariff is included in the unit price

Quantity
Unit Price
1
$21.16
5
$20.24
10
$19.32
20
$18.75

Specifications

Input Voltage:

115/230Vac User Selectable

Output Voltage:

24Vdc

Output Max Current:

6.5 Amps

Max Power:

156 Watts

Features

AC input: 85~132Vac / 170~264Vac selectable by switch

Working temperature: -30~+70°C

Safety standard: UL62368-1

IEC/EN61558-1,-2-16; IEC-EN60335-1; EN55022; EN55014

Withstand 300Vac surge input for 5 seconds

High efficiency

No load power consumption: <0.5W

Cooling: free air convection

Withstand 5G vibration test

Operation up to 5,000 meters

LED indicator for power on

Protections: short circuit / over load / over voltage / over temperature

MEAN WELL 3 year warranty

MEAN WELL LRS-150-24

LRS-150-24

24Vdc 6.5A, Power Supply, 24 Volts, 150 Watts

Manufacturer: MEAN WELL

View Data Sheet

Specifications

Input Voltage:

115/230Vac User Selectable

Output Voltage:

24Vdc

Output Max Current:

6.5 Amps

Max Power:

156 Watts

Features

AC input: 85~132Vac / 170~264Vac selectable by switch

Working temperature: -30~+70°C

Safety standard: UL62368-1

IEC/EN61558-1,-2-16; IEC-EN60335-1; EN55022; EN55014

Withstand 300Vac surge input for 5 seconds

High efficiency

No load power consumption: <0.5W

Cooling: free air convection

Withstand 5G vibration test

Operation up to 5,000 meters

LED indicator for power on

Protections: short circuit / over load / over voltage / over temperature

MEAN WELL 3 year warranty
