HDR-100-48
48Vdc 1.92A 48Vdc DIN Rail Power Supply UL508,UL60950-1 Pass LPSManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
1.92 Amps
Max Power:
92 Watts
Features
AC input range: 85~264Vac (277Vac available)
Operating temperature range: -30~+70°C
Safety approvals: UL60950-1 & UL508
Pass LPS
Class II isolation
LED indicator for power on
Low no load power consumption: <0.3W
Adjustable DC output voltage
Standard protections: short circuit / over load / over voltage
MEAN WELL 3 year warranty
HDR-100-48
48Vdc 1.92A 48Vdc DIN Rail Power Supply UL508,UL60950-1 Pass LPSManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
85~264Vac
Output Voltage:
48Vdc
Output Max Current:
1.92 Amps
Max Power:
92 Watts
Features
AC input range: 85~264Vac (277Vac available)
Operating temperature range: -30~+70°C
Safety approvals: UL60950-1 & UL508
Pass LPS
Class II isolation
LED indicator for power on
Low no load power consumption: <0.3W
Adjustable DC output voltage
Standard protections: short circuit / over load / over voltage
MEAN WELL 3 year warranty
