SFTN01L-09N
1W; I/P: 5VDC; O/P: 9VDC@111mA; SMD DC/DC Converter 1W Unregulated SMDManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$4.13
10
$4.08
25
$4.03
50
$3.97
100
$3.88
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
4.5~5.5Vdc
Output Voltage:
9Vdc
Output Max Current:
0.111 Amps
Max Power:
1 Watts
Features
Unregulated output
Operating temperature range: -40~+100°C
Input filter meets EN 55032 class A with external components
I/O isolation: 3,000Vdc
Protections: short circuit
MEAN WELL 3 year warranty
SFTN01L-09N
1W; I/P: 5VDC; O/P: 9VDC@111mA; SMD DC/DC Converter 1W Unregulated SMDManufacturer: MEAN WELL
View Data Sheet
Specifications
Input Voltage:
4.5~5.5Vdc
Output Voltage:
9Vdc
Output Max Current:
0.111 Amps
Max Power:
1 Watts
Features
Unregulated output
Operating temperature range: -40~+100°C
Input filter meets EN 55032 class A with external components
I/O isolation: 3,000Vdc
Protections: short circuit
MEAN WELL 3 year warranty
