DETN01M-05N
1W, I/P: 12VDC; O/P:+/-5V @+/-100mA DC/DC Converter 1W Unregulated, Dual Output SMD PackageManufacturer: MEAN WELL
View Data Sheet
Availability: Contact Us
i
Lead time for quantities greater than shown can be as short as 1 week. Call or submit an online Request for Quote for lead time.
Lead time for quantities greater than shown, contact us
Quantity
Unit Price
1
$4.40
10
$4.34
25
$4.29
50
$4.23
100
$4.13
REQUEST a QUOTE for higher qty discounts
Specifications
Input Voltage:
10.8~13.2Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
0.1 Amps
Output Voltage #2:
-5Vdc
Output #2 Max Current:
-0.1 Amps
Max Power:
1 Watts
Features
Unregulated output
Operating temperature range: -40~+100°C
Input filter meets EN 55032 class A with external components
I/O isolation: 3,000Vdc
Protections: short circuit
MEAN WELL 3 year warranty
